Jeil SNA ATTACHMENT
Jeil SNA ATTACHMENT
ATTACHMENT
ROCK SAW
Certified with Europe CE standard
Ready to work any work place in the world.Our original design, easy for maintenance
ADS-20RS (M850)
Model Name : ADS-20RS (M850)
Suitable Excavator : 20~45 Tons
-
Working Parameters
Items Parameters Unit Max Output power 160 kW Max Flow 380 LPM Recommended Flow 200-300 LPM Max Presure 320 bar Output shaft speed 0~450 RPM Output torque 3200 Nm@320bar Unit weight 550 kg Saw disc spec. ￠2000~3800 mm Material for cutting
granite; basalt, Rebar
Concrete, Marble, linestone
Remaeks :
(1) Different saw blades are available for cutting different
materials such as aluminium, concrete rebar mixed material
(2) It can mounted to any type of hydraulic machine
ADS-15RS (M600)
Model Name : ADS-15RS (M600)
Suitable Excavator : 15~25 Tons
-
Working Parameters
Items Parameters Unit Max Output power 120 kW Max Flow 250 LPM Recommended Flow 150-230 LPM Max Presure 320 bar Output shaft speed 0~500 RPM Output torque 2610 Nm@320bar Unit weight 450 kg Saw disc spec. ￠1600~2600 mm Material for cutting
granite; basalt, Rebar
Concrete, Marble, linestone
Remaeks :
(1) Different saw blades are available for cutting different
materials such as aluminium, concrete rebar mixed material
(2) It can mounted to any type of hydraulic machine
ADS-10RS (6K/310/390/490)
Model Name : ADS-10RS
Suitable Excavator : 8~16 Tons
-
Working Parameters
Items Parameters Unit Max Output power 70 kW Max Flow 180 LPM Recommended Flow 100-150 LPM Max Presure 310 bar Output shaft speed 0~600 RPM Output torque 1450 Nm@320bar Unit weight 350 kg Saw disc spec. ￠1400~2000 mm Material for cutting
granite; basalt, Rebar
Concrete, Marble, linestone
Remaeks :
(1) Different saw blades are available for cutting different
materials such as aluminium, concrete rebar mixed material
(2) It can mounted to any type of hydraulic machine
ADS-05RS (4K/110/160/205/245/310)
Model Name : ADS-05RS
Suitable Excavator : 3~8 Tons
-
Working Parameters
Items Parameters Unit Max Output power 41 kW Max Flow 150 LPM Recommended Flow 60-100 LPM Max Presure 310 bar Output shaft speed 0~600 RPM Output torque 600 Nm@320bar Unit weight 250 kg Saw disc spec. ￠1000~1800 mm Material for cutting
granite; basalt, Rebar
Concrete, Marble, linestone
Remaeks :
(1) Different saw blades are available for cutting different
materials such as aluminium, concrete rebar mixed material
(2) It can mounted to any type of hydraulic machine
GALLERY
Certified with Europe CE standard
Easier and Faster maintenance
High impact energy and Low noise level
