Jeil SNA ATTACHMENT

GRAB
Certified with Europe CE standard
Ready to work any work place in the world.Our original design, easy for maintenance

MODEL	SG03	SG05	SG08	SG10	SG11
Weight	280 KG	730 KG	1450 KG	1850 KG	2480 KG
A(mm)	960	1340	1570	1645	1900
B(mm)	1160	1630	1870	2110	2430
H(mm)	880	1210	1425	1540	1730
L(mm)	450	650	800	850	950
Working pressure	110 - 150	150 - 170	160 - 200	160 - 210	180 - 210
Carrier weight (ton)	04 - 06	08 - 13	18 - 22	28 - 32	33 - 39

MODEL	NSG03	NSG05	NSG08	NSG10
Carrier weight (ton)	04 - 06 TON	09 - 13 TON	18 - 22 TON	28 - 35 TON
A	1300mm	1800mm	2240mm	2460mm
B	366mm	510mm	640mm	700mm
W	396mm	550mm	650mm	700mm
H	1200mm	1690mm	2100mm	2300mm
Weight	420kg	950kg	2200kg	2300kg
Working Pressure	100 - 200 kg/㎠	150 - 220 kg/㎠	160 - 240 kg/㎠	160 - 240 kg/㎠
Setting Pressure ( cylinder)	250 kg/㎠	250 kg/㎠	260 kg/㎠	260 kg/㎠
Oil Flow	30 - 50 l/min	90 - 120 l/min	100 - 150 l/min	130 - 200 l/min

Certified with Europe CE standard
Easier and Faster maintenance
High impact energy and Low noise level
